NCAT Case Study: Non-Compliant Waterstop in Residential Shower Causes Water Damage
Client
Homeowner – Sydney, NSW
Project Type
Residential Bathroom Renovation
Dispute Forum
NSW Civil and Administrative Tribunal (NCAT)
Expert Services Provided
- Building Defect Inspection
- Expert Witness Report
- Waterproofing Assessment
- Scott Schedule Preparation
- NCAT Litigation Support
Background
The homeowner engaged a licensed contractor to undertake a complete bathroom renovation within a residential dwelling in Sydney, New South Wales. The works included demolition, waterproofing, tiling, plumbing fixtures, and associated finishes.
Approximately 12 months after completion of the renovation works, the homeowner began experiencing water leakage from the shower area into adjacent floor coverings and wall linings. Moisture staining became evident to the skirting boards outside the bathroom and swelling of the door jambs was observed.
Despite several requests for rectification, the builder denied responsibility and claimed the shower was performing as intended.
The homeowner subsequently engaged Awesim Building Consultants to undertake an independent building inspection and prepare an Expert Witness Report for NCAT proceedings.
Inspection Findings
During the site inspection, Awesim Building Consultants identified multiple defects associated with the shower construction.
The most significant defect involved the absence of a compliant waterstop at the shower entry.
Observations included:
- No visible waterstop installed beneath the shower screen.
- Waterproofing membrane terminated without adequate vertical upturn.
- Shower threshold finished flush with the adjoining bathroom floor.
- Water migration occurring beyond the shower enclosure.
- Moisture readings indicating elevated moisture levels outside the shower area.
- Damage to adjacent finishes consistent with long-term water exposure.
Expert Opinion
In our opinion, the shower was not constructed in accordance with accepted building practices for wet areas and did not adequately restrict the movement of water from the shower area into adjacent sections of the bathroom.
The absence of a compliant waterstop significantly increased the risk of water escaping the shower recess and bypassing the waterproofing system.
The observed damage was consistent with foreseeable water migration resulting from inadequate detailing at the shower threshold.
The defect was considered a breach of the contractor’s obligation to perform the work with due care and skill and in accordance with the relevant standards applicable at the time of construction.
Homeowner’s Claim
The homeowner sought orders through NCAT for:
- Removal and replacement of defective shower works.
- Rectification of waterproofing defects.
- Replacement of damaged floor finishes.
- Replacement of affected wall linings and trim.
- Reimbursement of expert report costs.
- Associated rectification expenses.
The total claim exceeded $30,000.
Builder’s Defence
The builder asserted:
- The shower remained functional.
- Waterstop installation was not required.
- The water leakage was caused by occupant use.
- Any damage was minor and cosmetic.
The builder did not provide evidence demonstrating compliance with the applicable waterproofing requirements or industry standards.
NCAT Proceedings
Awesim Building Consultants prepared an Expert Witness Report detailing:
- The defects identified during inspection.
- The mechanism by which water escaped the shower enclosure.
- The consequences of non-compliant construction.
- The scope of rectification required.
- Estimated rectification costs.
A Scott Schedule was also prepared to clearly identify each defect, the homeowner’s position, the builder’s response, and the expert’s findings.
The report assisted the Tribunal in understanding the technical issues associated with the shower construction.
Outcome
Following the exchange of expert evidence, the parties entered settlement negotiations.
The builder ultimately agreed to:
- Remove and reconstruct the shower area.
- Install a compliant waterproofing system.
- Undertake associated remedial works.
- Contribute towards the homeowner’s expert costs.
The matter resolved without the need for a final hearing.
Lessons for Homeowners
Waterstop defects are among the most common causes of shower leakage disputes in residential construction.
Many bathroom failures are not immediately visible and may take months or years before evidence of water damage becomes apparent.
Homeowners should seek independent expert advice where:
- Water escapes from shower areas.
- Bathroom floor tiles crack or move.
- Waterproofing defects are suspected.
- Builders deny responsibility for ongoing leakage.
Early investigation can significantly reduce the extent of damage and improve the prospects of a successful claim.
